LC-SC fiber optic patch leads 2.0mm Zipcord For Connection Between Transceivers

Brand Name : OEM

Model Number : LC/UPC-SC/UPC-2F-2.0-10M

Certification : ISO9001

Place of Origin : CHINA

MOQ : Support sample order

Price : Negotiation

Payment Terms : T/T, Western Union, L/C

Supply Ability : 1000,000 connectors/month

Delivery Time : 3-7 work days

Packaging Details : Individual packaging with Ziplock Bag

Fiber Type : G657A2

Cable Material : OFNR

Fiber Count : 2 Fibers

Polish Type : UPC

Cable Color : RED

Connector Type : SC, LC

Contact Now

2.0MM ZIPCORD DUPLEX PATCH CORD RED SM LC - SC FOR THE CONNECTION BETWEEN TRANSCEIVERS

ORC supplies a wide range of fiber optic patch cords, manufacturing and developing high quality optic connection products for the demanding of network applications. Both ends are terminated with high performance hybrid or single type connector, which includes SC, LC, ST, FC, E2000(LSH), MU, MTRJ and so on.

Features

◆ High concentricity 2.5mm ceramic ferrule for SC, FC, ST; 1.25mm ceramic ferrule for LC and MU

◆ Standard colour is Yellow, Orange, Aqua or Purple, other colours available upon request

◆ Low insertion loss, high return loss, high dense connection and easy for operation

◆ 100% tested on optical performance with testing result label stuck on package bag

Standard compliance

◆ ISO/IEC 11801 2nd Ed., CENELEC EN 50173

◆ Telcordia (formerly Bellcore) GR-326-CORE Generic requirements for Single mode optical connectors and Jumper assemblies

◆ Cable flame resistant rate: OFNR or IEC60332-3 standard

Specification

LC-SC fiber optic patch leads 2.0mm Zipcord For Connection Between Transceivers

1. Optical Performance

Item	SM		MM
	1310nm/1550nm IL(dB)	1310nm/1550nm RL(dB)	850nm IL(dB)	850nm RL(dB)
PC	<=0.20	>=50	<=0.30	>=25
APC	<=0.30	>=60	N/A	N/A

2. Material data

Range of mode	Single mode
Cable type	Duplex zipcord
Connector style	SC, LC
Ferrule interface type	PC, UPC, APC
Cable diameter	0.9mm, 1.6mm, 1.8mm, 2.0mm, 3.0mm
Length	Customize
Strength member	Aramid yarn
Outer jacket	OFNR(PVC, LSZH, OFNP optional)
Cable Assembly Length (<20 meter Tolerance)	±0.1M
Cable Assembly Length (>20 meter Tolerance)	±1%
Jacket Color (Multimode: OM1 & OM2)	Orange
Jacket Color (Multimode: OM3)	Aqua
Jacket Color (Multimode: OM4)	Aqua or violet
Jacket Color (Single Mode: G652D & Gb57A)	Yellow
Operation temp.	-20-+60℃
Storage temp.	-20-+60℃

Ordering information

Connector type

Fiber type

Fiber count

Boot fit for cable diameter

Length

Jacket material

SCA/SCU

LCA/LCU

FCA/FCU

STA/STU

E2000A/E2000U

SCA/SCU

LCA/LCU

FCA/FCU

STA/STU

E2000A/E2000U

G652D

G657A1/G657A2

OM1

OM2

OM3

OM4

SX=1 core

DX=2 cores

0.9mm

1.6mm

1.8mm

2.0mm

3.0mm

0010=1M

0100=10M

PVC

LSZH

OFNR

OFNP
